• APC SRC2KUXI Smart UPS SRC 2000VA 1600W

APC SRC2KUXI Smart UPS SRC 2000VA 1600W


    • Model: SRC2KUXI
    • APC 230v, 2000 VA & 1600 Watts, 2 IEC 320 C13 output Ports
    • Warranty: 2 Years On-site Repair or replacement Warranty
    • Smart-UPS - Double Conversion Online Technology
    • Application - for Server/ Voice & Data/Network/ MedicalLabs & Light Industrial
    • Battery Bar-graphs and On Line : On Battery : Replace Battery and Overload Indicators
    • Authorised APC Partner

    Rs 35990 (inclusive of all taxes)
    Free Shipping
    → Fast Delivery in Bangalore within 1-2 Business Days

APC SRC2KUXI Smart UPS SRC 2000VA 1600W Description:

APC Smart-UPS Online range provides high density, true double conversion online power protection for servers, voice & data networks, medical labs and light industrial applications. The Smart-UPS Online models are ideally suitable for business critical systems that require long hour duration runtimes and work in a harsh environment. The Smart-UPS Online models are equipped with state of the art Power Chute management software to ensure additional safety for
network operating systems during power shutdowns and voltage fluctuation
s

SRC2KUXI SMART-UPS is an online type pure sinewave UPS from APC. This Smart UPS comes with an in-built fast charging, energy efficient maintenance free external battery systme operating at 72V. In Addition to this,  the 2000VA double conversion online UPS can act like a voltage stabalizer with its Automatic Voltage Regulation(AVR) functionality and performs power conditioning, which protects all the connected equipment from unsafe voltage levels and other disturbances. The four indian style output sockets can support loads up to 1600 Watts.

SRC2KUXI is the best in class & low priced pure sine wave UPS from APC to protect sensitive electronics (LED TV, LCD TV, computers, wired & wireless network devices) for homes, offices, financial institutions and hospitals.

2000 VA
1600 Watts

Up to
40 Mins
Back-UP Time
2 Years
Warranty

AVR
Technology



Typical Applications Back Up Time
All-in-one PC with 15" LCD Monitor 40 Min to 5 Hours
Home PC with 19" LCD Monitor 35 Min to 5 Hours
Home Performance PC with 22" LCD 20 Min to 5 Hours
Internet Modem & Wifi Router Upto 90 Mins to 10 Hours
32" LED TV Upto 30 Mins to 5 Hours
42" LED TV Upto 10 Mins to 4 Hours



  • Audible alarms - Gives warning of changing utility power and UPS power conditions with mild beeps.
  • Automatic self-test-Intermittent battery individual test guarantees early identification of a battery that should be supplanted.
  • Battery charge indication - Indicates the current state of battery (charging or charged)
  • Battery Saver- The UPS shuts down by itself when no load or low load is connected to increase the battery life.
  • Automatic Voltage Regulation (AVR) - Boosts low voltage to safe levels & trims high voltage to safe voltage level without switching over to the battery, thereby extending battery life.
  • Cold-start feature - It can provide power for a brief period even in the absense of mains.
  • Fast battery charging capability- It has the capability to recharge faster even after a deep discharge.
  • Compatibile with Generator - UPS can be charged once the generator kicks in.
  • LED status Indicators - Simple LED indicators to understand the UPS health & power conditions
  • Resettable circuit breaker- Simple recuperation from over load condition without the need for fuse replacement.
  • Short Circuit protection

APC SRC2KUXI Technical Specifications:

Output
Max output Power                                                                     1600 Watts / 2000 VA
Operating Output Voltage  230V
Operating Output Frequency  47 - 63 Hz
UPS Type  Double Conversion Online UPS
Output Waveform  Pure sinewave
Bypass  Built-in Bypass
Output Connections  (2) IEC 320 C13 (Battery Backup)
 (1) Hard Wire 3-wire (H N + G) (Battery Backup)
Transfer Time  4ms typical

Input

Operating Input Voltage  230V
Operating Input frequency   47 - 63 Hz
Input connector  Hard Wire 3 wire (1PH+N+G)
Input Cable lenght  1.52 meters
Operating Mains Voltage  140 - 280 V
Number of input power cable  1
Efficiency at Full Load  92.0%

Battery Information

Inbuilt Battery type   72V, SMF or Flooded battery compatible, internal charger 2A - 13A programmable
Recharge time  6 hour(s)
Inbuilt Battery Rating  No internal battery - uses external battery system

Back-UPS Management

LED status indication for On Line and On Battery condition : Replace Battery and Building Wiring Fault

Audible Alarm when on battery, distinctive alarm when the battery is low, continuous beep to indicate overload

Surge Protection and Filtering

Surge Protection   Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical Dimensions of SRC2KUXI

UPS Height   8.5 CM
UPS Width   43.2 CM
UPS Depth    48.3 CM
Weight of UPS only  10.5 KG
Shipping weight with packaging  13.5 KG
Box Height  26.5 CM
Box Width   57.5 CM
Box Depth  58.5 CM

Normal Operating Environment for SRC2KUXI

Normal Operating Temperature  0 to 40 °C
Operating Humidity  0 to 95 %
