APC SUA1000UXI 1000 VA Smart-UPS
- Boost and Trim Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models)
- Power conditioning : Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Cold-start capable : Provides temporary battery power when the utility power is out.
- Warranty : 2 Years On-site Warranty
APC SUA1000UXI 1000 VA Smart-UPS Description:
Output |
|
| Output Power Capacity | 800 Watts / 1000 VA |
| Max Configurable Power | 800 Watts / 1000 VA |
| Nominal Output Voltage | 230V |
| Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
| Output Voltage Distortion | Less than 5% at full load |
| Output Frequency (sync to mains) | 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal |
| Topology | Line Interactive |
| Waveform Type |
Sine wave
|
| Output Connections |
(8) IEC 320 C13 2) IEC Jumpers |
Input |
|
| Nominal Input Voltage | 230V |
| Input Frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections | IEC-320 C14 |
| Cord Length | 1.83 meters |
| Input voltage range for main operations | 160 - 285V |
| Input voltage adjustable range for mains operation | 151 - 302V |
Batteries & Runtime |
|
|
Battery Type
|
No internal battery - uses external battery system |
| Replacement battery cartridge note | See the UXI brochure for recharge rates |
Communications & Management |
|
|
Interface Port(s)
|
DB-9 RS-232, SmartSlot, USB |
| Available SmartSlot™ Interface Quantity | 1 |
| Control panel | LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Emergency Power Off (EPO) | Optional |
Surge Protection and Filtering |
|
| Surge energy rating | 480 Joules |
| Filtering | Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical |
|
| Maximum Height | 216.00 mm |
| Maximum Width | 170.00 mm |
| Maximum Depth | 439.00 mm |
| Net Weight | 12.91 KG |
| Shipping Weight | 15.00 KG |
| Shipping Height | 381.00 mm |
| Shipping Width | 330.00 mm |
| Shipping Depth | 584.00 mm |
| Color | Black |
| Units per Pallet | 24.00 |
Environmental |
|
| Operating Environment | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95% |
| Operating Elevation | 0-3000 meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95% |
| Storage Elevation | 0-15000 meters |
| Audible noise at 1 meter from surface of unit | 42.00 dBA |
| Online Thermal Dissipation | 120.00 BTU/hr |
Conformance |
|
|
Regulatory Approvals
|
C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE |
| Standard Warranty |
2 years repair or replace
|
